Model #:
FDSP4501AS
Color:
Stainless Steel
24" Stainless Steel Tub Built-In Dishwasher
24" Stainless Steel Tub Built-In Dishwasher
Dimensions
Width: 24
Height: 35 3/4
Depth: 24 1/4
Color
Stainless Steel
Features
- Unlike traditional spray arms, our BladeSpray® arm rotates in two directions, so you get better water coverage that reaches every corner.
- Save time loading and unloading and fit more with a third level rack that easily holds silverware, cooking utensils and tools.
- In the event of a leak a sensor is triggered stopping the cycle and containing overflowed water in a tray at the bottom of the dishwasher.
- With the fan assisted EvenDry™ system, air flow is evenly circulated and moisture is removed for clean, spot-free dishes every time.
- Remove 99.9% of common household bacteria with NSF-Certified Sanitize Option.
- Skip pre-rinsing with our DishSense® sensor technology that adjusts cleaning performance based on the soil level of your dishes.
- Make loading the dishwasher easier with adjustable racks and enough space to fit large dishes.
- Keep your kitchen quiet and the noise inside your dishwasher where it belongs with extra, quality insulation.
- Save money and maximize energy efficiency.
- 5 Wash cycles including heavy, normal, china/crystal, energy saver, rinse only.
Product Description
The Frigidaire 24" Stainless Steel Tub Built-In Dishwasher offers thorough cleaning from corner to corner with our BladeSpray®, which provides better water coverage compared to our traditional spray arm. Plus, enjoy an enhanced dry with MaxDry™, which delivers better results reducing the need for towel drying. This quiet dishwasher (49 dBA) also includes a sanitize option, third level rack, and is Energy Star® certified.
Rebates
Specification
| Certifications and Approvals | |
| ADA Compliant | No |
| CEE Tier | Tier 1 |
| cUL Listed | Yes |
| ENERGY STAR Certified | Yes |
| ETL Listed | Yes |
| NSF Certified | Yes |
| UL Listed | Yes |
| Controls | |
| Control Location | Top |
| Delay Start Hours | 1-24 Hours |
| Dimensions and Volume | |
| Minimum Height | 33 3/4" |
| Depth With Door Open | 50 1/4" |
| Dishwasher | |
| Automatic Temperature Control | No |
| Detergent Dispenser | Yes |
| Filter Material | Stainless Steel |
| Filter Trap | Removable |
| Filtered Water | 100 % |
| Hard Food Disposer or Filtration | Yes |
| Motor Speeds | Multi-Speed |
| Place Setting Capacity | 14 |
| Smart Soil Sensor | Yes |
| Lower Spray Arm | Blade |
| Middle Spray Arm | Bi-Beam |
| Upper Spray Arm | Spray Arm |
| Tub Color | Stainless Steel |
| Tub Design | Tall Tub |
| Tub Material | Stainless Steel |
| Wash Levels | 5 |
| Wash System | Direct Feed |
| Water Pressure | 120 psi |
| Dishwasher Cycles | |
| China Crystal | Yes |
| Energy Saver | Yes |
| Heavy | Yes |
| Normal | Yes |
| Number of Cycles | 5 |
| Rinse Only | Yes |
| Dishwasher Options | |
| Drying System | Fan Assist |
| Heated Dry | Yes |
| High Temperature | Yes |
| Start/Cancel | Yes |
| Electrical Specifications | |
| Voltage Rating | 120 V |
| Exterior | |
| Door and Handle Design | |
| Door Type | Standard |
| General Specifications | |
| Sound Level | 49 dBA |
| Annual Energy | 240 kWh |
| Product Weight | 86 lbs |
| Prop 65 Label | No |
| Warranty - Labor | 1 Year |
| Warranty - Parts | 1 Year |
| Installation | |
| Number of Leveling Legs | 0 |
| Lower Rack | |
| Number of Silverware Basket | 1 |
| Rack Coating | Nylon |
| Rack Type | Deluxe |
| Third Level Rack | |
| Third Level Rack | Yes |
| Rack Coating | Nylon |
| Upper Rack | |
| Rack Coating | Nylon |
